Ammann AV 130 X Specifications & Technical Data (2010-2013)

Technical specs - AV 130 X Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 13.62 t

Transport length: 4.89 m

Transport width: 2.22 m

Transport height: 3.05 m

Vibration: e/d

Steering: KL

Travel speed: 11 km/h

Frequency: 55 Hz

Roller width: 2.1 m

Rollers Ø: 0.785 m

Statical line load: 29.8 kg/cm

Model series: AV

Engine manuf.: Cummins

Engine type: QSB4.5-C130

Engine power: 97 kW

Displacement: 4.5 l

Revolutions at max torque: 2200 rpm

More technical details, like: drive, turning radius outside, centrifugal force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: Yes

Download datasheets (PDF)

Ammann AV 130 X FAQ

When was the Ammann AV 130 X manufactured?

The Ammann AV 130 X was manufactured from 2010 to 2013.

How much does the Ammann AV 130 X weigh?

The Ammann AV 130 X weighs 13.62 tons.

What are the transport dimensions of the Ammann AV 130 X tandem vibration roller?

The Ammann AV 130 X has a transport length of 4.89 meters, a transport width of 2.22 meters, and a transport height of 3.05 meters.

What is the travel speed of the Ammann AV 130 X tandem vibration roller?

The Ammann AV 130 X has a travel speed of 11 km/h.

What type of steering system does the Ammann AV 130 X use for maneuverability?

The Ammann AV 130 X uses an articulated-frame steering system for maneuverability.

What are the compaction capabilities of the Ammann AV 130 X tandem vibration roller?

The Ammann AV 130 X features both double and single vibration modes, operates at a frequency of 55 Hz, and has a statical line load of 29.8 kg/cm.

What are the roller specifications of the Ammann AV 130 X tandem vibration roller?

The Ammann AV 130 X has rollers that are 2.1 meters wide with a diameter of 0.785 meters.

How much is a Ammann AV 130 X Tandem Vibration Roller (2010u20132013) worth?

The residual value of the Ammann AV 130 X depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Ammann AV 130 X overview

Operator’s Station

Standard items

CE confirmity – ROPS, TIER II, seat switch ROPS/FOPS cab with sliding and rotating driver seat Ventilated+heated Adjustable steering wheel Speed pre-selector 2 mode vibratory system Hydrostatic propulsion, front+rear Working lights + turning indicators and back up lights Sprinkling system Back-up alarm Vulkolan scrapers Inter axle dif. lock

Optional items

Open platform with rails + vandal cover ROPS frame onto platform Canvas canopy (black, yellow), mounted on ROPS frame Canvas canopy (black, yellow) Air conditioning Radio with MP3 player Edge cutter + press wheel Thermometer Backing horn Additional working lights on cab 2+2 Tiltable scrapers Warning beacon Back-up alarm Tools kit First service kit Fire extinguisher Add. documentation set Special painting
