Ammann AV 110 X Specifications & Technical Data (2010-2013)

Technical specs - AV 110 X Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 11 t

Transport length: 4.76 m

Transport width: 1.822 m

Transport height: 3 m

Vibration: e/d

Steering: KL

Travel speed: 11 km/h

Frequency: 55 Hz

Roller width: 1.7 m

Rollers Ø: 0.76 m

Statical line load: 30.9 kg/cm

Model series: AV

Engine manuf.: Cummins

Engine type: 4BT4.5C99

Engine power: 74 kW

Revolutions at max torque: 2200 rpm

More technical details, like: drive, turning radius outside, centrifugal force, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: Yes

Download datasheets (PDF)

Ammann AV 110 X FAQ

When was the Ammann AV 110 X manufactured?

The Ammann AV 110 X was manufactured from 2010 to 2013.

How much does the Ammann AV 110 X weigh?

The Ammann AV 110 X weighs 11 tons.

What are the transport dimensions of the Ammann AV 110 X tandem vibration roller?

The Ammann AV 110 X has a transport length of 4.76 meters, a transport width of 1.82 meters, and a transport height of 3 meters.

What is the travel speed of the Ammann AV 110 X tandem vibration roller?

The Ammann AV 110 X tandem vibration roller has a travel speed of 11 km/h.

What type of steering does the Ammann AV 110 X use for maneuverability?

The Ammann AV 110 X uses articulated-frame steering for maneuverability.

What are the compaction capabilities of the Ammann AV 110 X tandem vibration roller?

The Ammann AV 110 X features both double and single vibration modes, operates at a frequency of 55 Hz, and has a statical line load of 30.9 kg/cm.

What are the roller specifications of the Ammann AV 110 X tandem vibration roller?

The Ammann AV 110 X has rollers that are 1.7 meters wide with a diameter of 0.76 meters.

How much is a Ammann AV 110 X Tandem Vibration Roller (2010u20132013) worth?

The residual value of the Ammann AV 110 X depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
