ARX 40-2 Ammann ARX 40-2 Specifications & Technical Data (2019—2021)
.jpg)
Technical specs - ARX 40-2 Ammann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 4.16 t
- Transport length
- 3 m
- Transport width
- 1.385 m
- Transport height
- 2.15 m
- Vibration
- d
- Drive
- A
- Steering
- KL
- Travel speed
- 10 km/h
- Frequency
- 55 Hz
- Roller width
- 1.3 m
- Rollers Ø
- 0.85 m
- Turning radius outside
- 2.83 m
- Statical line load
- 16.6 kg/cm
- Centrifugal force
- 55 kN
- Model series
- Light Tandem Rollers
- Engine manuf.
- Kubota
- Engine type
- D1803-CR-E4B
- Engine power
- 32.6 kW
- Revolutions at max torque
- 2400 rpm
- No. of cylinders
- 3
- Emission level
- Tier 4 f
More technical details, like: dimension lxwxh, displacement, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
Yes
- Oscillation
-
No
- Compression control
-
Yes
- Aircondition
-
No
Download datasheets (PDF)
Ammann ARX 40-2 FAQ
How much does the Ammann ARX 40-2 weigh?
What are the transport dimensions of the Ammann ARX 40-2 tandem vibration roller?
What is the travel speed of the Ammann ARX 40-2 tandem vibration roller?
What type of drive system does the Ammann ARX 40-2 have in its undercarriage?
What are the maneuverability specifications of the Ammann ARX 40-2 tandem vibration roller?
What are the compaction capabilities of the Ammann ARX 40-2 tandem vibration roller?
What are the roller specifications of the Ammann ARX 40-2 tandem vibration roller?
