ARX 40 Ammann ARX 40 Specifications & Technical Data (2013—2021)
.jpg)
.jpg)
Technical specs - ARX 40 Ammann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 4.12 t
- Transport length
- 2.8 m
- Transport width
- 1.34 m
- Transport height
- 2.33 m
- Vibration
- d
- Drive
- A
- Steering
- KL
- Travel speed
- 10 km/h
- Frequency
- 57 Hz
- Roller width
- 1.34 m
- Rollers Ø
- 0.85 m
- Turning radius outside
- 2.58 m
- Statical line load
- 15.8 kg/cm
- Centrifugal force
- 52 kN
- Model series
- ARX
- Engine manuf.
- Yanmar
- Engine type
- 4TNV88
- Engine power
- 30 kW
- Displacement
- 2.189 l
- Revolutions at max torque
- 2400 rpm
More technical details, like: dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
