Technical specs - ARX 20-2 Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.57 t

Transport length: 3 m

Transport width: 1.05 m

Transport height: 1.94 m

Vibration: d

Drive: A

Steering: KL

Travel speed: 8.4 km/h

Frequency: 70 Hz

Roller width: 1 m

Rollers Ø: 0.58 m

Statical line load: 8.5 kg/cm

Model series: ARX

Engine manuf.: Kubota

Engine type: D1803-CR

Engine power: 25 kW

No. of cylinders: 3

Emission level: EU V

More technical details, like: turning radius outside, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

Ammann ARX 20-2 FAQ

When was the Ammann ARX 20-2 manufactured?

The Ammann ARX 20-2 was manufactured from 2018 to 2020.

How much does the Ammann ARX 20-2 weigh?

The Ammann ARX 20-2 weighs 1.57 tons.

What are the transport dimensions of the Ammann ARX 20-2 tandem vibration roller?

The Ammann ARX 20-2 has a transport length of 3 meters, a transport width of 1.05 meters, and a transport height of 1.94 meters.

What is the travel speed of the Ammann ARX 20-2 tandem vibration roller?

The Ammann ARX 20-2 tandem vibration roller has a travel speed of 8.4 km/h.

What type of undercarriage drive does the Ammann ARX 20-2 have?

The Ammann ARX 20-2 has an all-wheel drive undercarriage system.

What type of steering does the Ammann ARX 20-2 use for maneuverability?

The Ammann ARX 20-2 uses articulated-frame steering for maneuverability.

What are the compaction capabilities of the Ammann ARX 20-2 tandem vibration roller?

The Ammann ARX 20-2 features a double vibration system, operates at a frequency of 70 Hz, and has a statical line load of 8.5 kg/cm.

What are the roller specifications of the Ammann ARX 20-2 tandem vibration roller?

The Ammann ARX 20-2 has rollers that are 1 meter wide with a diameter of 0.58 meters.
