ARX 16-2 Ammann ARX 16-2 Specifications & Technical Data (2021—2026)
.jpg)
.jpg)
Technical specs - ARX 16-2 Ammann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 1.51 t
- Transport length
- 2.14 m
- Transport width
- 0.95 m
- Transport height
- 1.725 m
- Vibration
- d
- Drive
- A
- Steering
- KL
- Travel speed
- 8.1 km/h
- Frequency
- 70 Hz
- Roller width
- 0.9 m
- Rollers Ø
- 0.58 m
- Statical line load
- 9 kg/cm
- Centrifugal force
- 23 kN
- Model series
- ARX
- Engine manuf.
- Kubota
- Engine type
- D1105
- Engine power
- 15.6 kW
- No. of cylinders
- 3
- Emission level
- EU V
More technical details, like: turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
Ammann ARX 16-2 FAQ
How much does the Ammann ARX 16-2 weigh?
What are the transport dimensions of the Ammann ARX 16-2 tandem vibration roller?
What is the travel speed of the Ammann ARX 16-2 tandem vibration roller?
What is the undercarriage drive type of the Ammann ARX 16-2?
What type of steering does the Ammann ARX 16-2 use for maneuverability?
What are the compaction capabilities of the Ammann ARX 16-2 tandem vibration roller?
What are the roller specifications of the Ammann ARX 16-2 tandem vibration roller?
