ARX 12 T4f Ammann ARX 12 T4f Specifications & Technical Data (2018—2021)
.jpg)
.jpg)
Technical specs - ARX 12 T4f Ammann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 1.46 t
- Transport length
- 2.02 m
- Transport width
- 0.87 m
- Transport height
- 1.73 m
- Vibration
- d
- Steering
- KL
- Travel speed
- 8.5 km/h
- Frequency
- 66 Hz
- Roller width
- 0.87 m
- Rollers Ø
- 0.58 m
- Statical line load
- 8.4 kg/cm
- Centrifugal force
- 23 kN
- Model series
- ARX
- Engine manuf.
- Yanmar
- Engine type
- 3TNV80F
- Engine power
- 14.6 kW
- Revolutions at max torque
- 1800 rpm
- Emission level
- EU V
More technical details, like: drive, turning radius outside, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
