ARP 95 Ammann ARP 95 Specifications & Technical Data (2013—2019)
.jpg)
.jpg)
.jpg)
.jpg)
Technical specs - ARP 95 Ammann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 9.6 t
- Transport length
- 4.42 m
- Transport width
- 1.79 m
- Transport height
- 3 m
- Vibration
- d
- Steering
- VL
- Travel speed
- 10.5 km/h
- Frequency
- 55 Hz
- Roller width
- 1.68 m
- Rollers Ø
- 1.22 m
- Turning radius outside
- 2.95 m
- Statical line load
- 29.1 kg/cm
- Centrifugal force
- 92 kN
- Model series
- Heavy Tandem Rollers
- Engine manuf.
- Deutz
- Engine type
- TCD3.6 L4
- Engine power
- 74.4 kW
- Displacement
- 3.6 l
- Emission level
- Tier 4 i
More technical details, like: drive, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
