ARP 35 Ammann ARP 35 Specifications & Technical Data (2011—2020)
.jpg)
.jpg)
.jpg)
.jpg)
Technical specs - ARP 35 Ammann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 3.2 t
- Transport length
- 3 m
- Transport width
- 1.198 m
- Transport height
- 2.4 m
- Vibration
- e/d
- Steering
- DSL
- Travel speed
- 10 km/h
- Frequency
- 60 Hz
- Roller width
- 1.1 m
- Rollers Ø
- 0.8 m
- Turning radius outside
- 2.39 m
- Statical line load
- 14.5 kg/cm
- Centrifugal force
- 35 kN
- Model series
- ARP
- Engine manuf.
- Deutz
- Engine type
- D2011 L03i
- Engine power
- 36 kW
- Revolutions at max torque
- 2550 rpm
More technical details, like: drive, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
