Technical specs - YZ36 Zoomlion

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 36 t

Transport length: 7.15 m

Transport width: 2.78 m

Transport height: 3.37 m

Vibration: e

Drive: E

Travel speed: 12 km/h

Frequency: 32 Hz

Roller width: 1.8 m

Rollers Ø: 2.4 m

Amplitude: 2.5 mm

Turning radius outside: 6.4 m

Model series: YZ

Engine manuf.: Deutz

Engine type: N/A

More technical details, like: turning radius inside, statical line load, centrifugal force, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: No

Zoomlion YZ36 FAQ

When was the Zoomlion YZ36 manufactured?

The Zoomlion YZ36 was manufactured from 2017 to 2020.

How much does the Zoomlion YZ36 weigh?

The Zoomlion YZ36 weighs 36 tons.

What are the transport dimensions of the Zoomlion YZ36 single-drum roller?

The Zoomlion YZ36 has a transport length of 7.15 meters, a transport width of 2.78 meters, and a transport height of 3.37 meters.

What is the travel speed of the Zoomlion YZ36 single-drum roller?

The Zoomlion YZ36 has a travel speed of 12 km/h.

What type of drive system does the Zoomlion YZ36 use in its undercarriage?

The Zoomlion YZ36 uses a simple drive system in its undercarriage.

What is the turning radius of the Zoomlion YZ36 single-drum roller?

The Zoomlion YZ36 has an outside turning radius of 6.4 meters.

What are the compaction capabilities of the Zoomlion YZ36 single-drum roller?

The Zoomlion YZ36 features a single vibration system with a frequency of 32 Hz and an amplitude of 2.5 mm.

What are the roller specifications of the Zoomlion YZ36 single-drum roller?

The Zoomlion YZ36 has a roller width of 1.8 meters and a roller diameter of 2.4 meters.

How much is a Zoomlion YZ36 Single-drum Roller (2017u20132020) worth?

The residual value of the Zoomlion YZ36 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
