YZ35A Zoomlion YZ35A Specifications & Technical Data (2017—2020)

Weight: 35t – Transport length: 7.15m – Transport width: 2.78m – Transport height: 3.37m – Vibration: e – Drive: E

Rollers Single-drum Rollers Zoomlion YZ35A
Rollers Single-drum Rollers Zoomlion YZ35A
Rollers Single-drum Rollers Zoomlion YZ35A
Rollers Single-drum Rollers Zoomlion YZ35A

Technical specs - YZ35A Zoomlion

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
35 t
Transport length
7.15 m
Transport width
2.78 m
Transport height
3.37 m
Vibration
e
Drive
E
Travel speed
8 km/h
Frequency
32 Hz
Roller width
1.8 m
Rollers Ø
2.4 m
Amplitude
2.5 mm
Turning radius outside
6.4 m
Model series
YZ
Engine manuf.
Cummins
Engine type
N/A

More technical details, like: turning radius inside, statical line load, centrifugal force, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Sheep foot
No
Oscillation
No
Compression control
No
Aircondition
No

Zoomlion YZ35A FAQ

When was the Zoomlion YZ35A manufactured?

The Zoomlion YZ35A was manufactured from 2017 to 2020.

How much does the Zoomlion YZ35A weigh?

The Zoomlion YZ35A weighs 35 tons.

What are the transport dimensions of the Zoomlion YZ35A single-drum roller?

The Zoomlion YZ35A has a transport length of 7.15 meters, a transport width of 2.78 meters, and a transport height of 3.37 meters.

What is the travel speed of the Zoomlion YZ35A single-drum roller?

The Zoomlion YZ35A single-drum roller has a travel speed of 8 km/h.

What is the undercarriage drive of the Zoomlion YZ35A?

The Zoomlion YZ35A has a Simple drive.

What is the turning radius of the Zoomlion YZ35A single-drum roller?

The Zoomlion YZ35A has an outside turning radius of 6.4 meters.

What are the compaction capabilities of the Zoomlion YZ35A single-drum roller?

The Zoomlion YZ35A features a single vibration system with a frequency of 32 Hz and an amplitude of 2.5 mm.

What are the roller specifications of the Zoomlion YZ35A single-drum roller?

The Zoomlion YZ35A has a roller width of 1.8 meters and a roller diameter of 2.4 meters.

How much is a Zoomlion YZ35A Single-drum Roller (2017u20132020) worth?

The residual value of the Zoomlion YZ35A depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
