YTO YZD-4.5 Specifications & Technical Data (2017-2026)

Technical specs - YZD-4.5 YTO

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.5 t

Transport length: 3.9 m

Transport width: 1.4 m

Transport height: 2.4 m

Frequency: 50 Hz

Roller width: 1.2 m

Rollers Ø: 1 m

Turning radius outside: 4 m

Model series: YZD

Engine manuf.: Xinchai

Engine type: C490BPG

Engine power: 35 kW

More technical details, like: vibration, drive, travel speed, amplitude, turning radius inside, statical line load, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: vibration, drive, travel speed, amplitude, turning radius inside, statical line load, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: No

YTO YZD-4.5 FAQ

When was the YTO YZD-4.5 manufactured?

The YTO YZD-4.5 was first produced in 2017.

How much does the YTO YZD-4.5 weigh?

The YTO YZD-4.5 weighs 4.5 tons.

What are the transport dimensions of the YTO YZD-4.5 single-drum roller?

The YTO YZD-4.5 has a transport length of 3.9 meters, a transport width of 1.4 meters, and a transport height of 2.4 meters.

What is the turning radius of the YTO YZD-4.5 single-drum roller?

The YTO YZD-4.5 has an outside turning radius of 4 meters.

What is the vibration frequency of the YTO YZD-4.5's compaction system?

The compaction system of the YTO YZD-4.5 operates at a vibration frequency of 50 Hz.

What are the roller specifications of the YTO YZD-4.5 single-drum roller?

The YTO YZD-4.5 has a roller width of 1.2 meters and a roller diameter of 1 meter.
