AW 1070 e weycor AW 1070 e Specifications & Technical Data (2016—2019)

Weight: 7.1t – Transport length: 5.032m – Transport width: 1.85m – Transport height: 2.723m – Vibration: e – Drive: A

Rollers Single-drum Rollers weycor AW 1070 e
Rollers Single-drum Rollers weycor AW 1070 e
Rollers Single-drum Rollers weycor AW 1070 e
Rollers Single-drum Rollers weycor AW 1070 e
Rollers Single-drum Rollers weycor AW 1070 e
Rollers Single-drum Rollers weycor AW 1070 e
Rollers Single-drum Rollers weycor AW 1070 e
Rollers Single-drum Rollers weycor AW 1070 e
Rollers Single-drum Rollers weycor AW 1070 e
Rollers Single-drum Rollers weycor AW 1070 e

Visit weycor live at

Technical specs - AW 1070 e weycor

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.1 t
Transport length
5.032 m
Transport width
1.85 m
Transport height
2.723 m
Vibration
e
Drive
A
Travel speed
10 km/h
Frequency
40 Hz
Roller width
1.7 m
Rollers Ø
1.25 m
Amplitude
1.8 mm
Turning radius outside
5.6 m
Statical line load
22.4 kg/cm
Model series
AW
Engine manuf.
Deutz
Engine type
TD2.9 L4
Engine power
61.5 kW

More technical details, like: turning radius inside, centrifugal force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Sheep foot
Yes
Oscillation
No
Compression control
Yes
Aircondition
No

Download datasheets (PDF)

weycor AW 1070 e FAQ

When was the weycor AW 1070 e manufactured?

The weycor AW 1070 e was manufactured from 2016 to 2019.

How much does the Weycor AW 1070 e weigh?

The Weycor AW 1070 e weighs 7.1 tons.

What are the transport dimensions of the weycor AW 1070 e single-drum roller?

The transport dimensions of the weycor AW 1070 e are 5.03 meters in length, 1.85 meters in width, and 2.72 meters in height.

What is the travel speed of the weycor AW 1070 e single-drum roller?

The travel speed of the weycor AW 1070 e is 10 km/h.

What type of drive system does the weycor AW 1070 e use for its undercarriage?

The weycor AW 1070 e uses an all-wheel drive system for its undercarriage.

What is the turning radius of the Weycor AW 1070 e single-drum roller?

The Weycor AW 1070 e has an outside turning radius of 5.6 meters.

What are the compaction capabilities of the weycor AW 1070 e single-drum roller?

The weycor AW 1070 e features a single vibration system with a frequency of 40 Hz, an amplitude of 1.8 mm, and a statical line load of 22.4 kg/cm.

What are the roller specifications of the weycor AW 1070 e single-drum roller?

The weycor AW 1070 e has a roller width of 1.7 meters and a roller diameter of 1.25 meters.

How much is a weycor AW 1070 e Single-drum Roller (2016u20132019) worth?

The residual value of the weycor AW 1070 e depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
