Technical specs - SD70D Volvo
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 7.2 t
- Transport length
- 4.97 m
- Transport width
- 1.88 m
- Transport height
- 2.94 m
- Vibration
- e
- Drive
- A
- Travel speed
- 13 km/h
- Frequency
- 33.8 Hz
- Roller width
- 1.68 m
- Rollers Ø
- 1.219 m
- Amplitude
- 1.98 mm
- Model series
- SD
- Engine manuf.
- Cummins
- Engine type
- 4BT3.9
- Engine power
- 71 kW
- Displacement
- 3.9 l
More technical details, like: turning radius outside, turning radius inside, statical line load, centrifugal force, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
