Liugong 6626E Specifications & Technical Data (2016-2026)

Technical specs - 6626E Liugong

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 26 t

Transport length: 6.5 m

Transport width: 2.5 m

Transport height: 3.15 m

Travel speed: 10.4 km/h

Frequency: 33 Hz

Roller width: 2.13 m

Rollers Ø: 1.7 m

Amplitude: 1.8 mm

Turning radius outside: 7 m

Centrifugal force: 480 kN

Model series: E

More technical details, like: vibration, drive, turning radius inside, statical line load, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: vibration, drive, turning radius inside, statical line load, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: Yes

Liugong 6626E FAQ

When was the Liugong 6626E manufactured?

The Liugong 6626E was first produced in 2016.

How much does the Liugong 6626E weigh?

The Liugong 6626E weighs 26 tons.

What are the transport dimensions of the Liugong 6626E single-drum roller?

The Liugong 6626E has a transport length of 6.5 meters, a transport width of 2.5 meters, and a transport height of 3.15 meters.

What is the travel speed of the Liugong 6626E single-drum roller?

The Liugong 6626E has a travel speed of 10.4 km/h.

What is the turning radius of the Liugong 6626E single-drum roller?

The Liugong 6626E has an outside turning radius of 7 meters.

What are the compaction capabilities of the Liugong 6626E single-drum roller?

The Liugong 6626E single-drum roller operates at a frequency of 33 Hz, has an amplitude of 1.8 mm, and generates a centrifugal force of 480 kN.

What are the roller specifications of the Liugong 6626E single-drum roller?

The Liugong 6626E has a roller width of 2.13 meters and a roller diameter of 1.7 meters.

How much is a Liugong 6626E Single-drum Roller (2016u20132025) worth?

The residual value of the Liugong 6626E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
