H 25i C R Hamm H 25i C R Specifications & Technical Data (2021—2026)
Visit Hamm live at
Technical specs - H 25i C R Hamm
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 24.88 t
- Transport length
- 6.75 m
- Transport width
- 2.54 m
- Transport height
- 2.97 m
- Travel speed
- 6.9 km/h
- Frequency
- 30 Hz
- Roller width
- 2.22 m
- Rollers Ø
- 1.6 m
- Amplitude
- 2.01 mm
- Turning radius inside
- 4.76 m
- Centrifugal force
- 315 kN
- Model series
- H
- Engine manuf.
- Deutz
- Engine type
- TCD 6.1 L4
- Engine power
- 160 kW
- Displacement
- 6.1 l
- No. of cylinders
- 6
- Emission level
- EU Stage V / EPA Tier 4
More technical details, like: vibration, drive, turning radius outside, statical line load, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
