Hamm H 25i Specifications & Technical Data (2014-2026)

Technical specs - H 25i Hamm

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 24.92 t

Transport length: 6.6 m

Transport width: 2.51 m

Transport height: 2.97 m

Vibration: e

Travel speed: 12 km/h

Frequency: 30 Hz

Roller width: 2.14 m

Rollers Ø: 1.6 m

Amplitude: 2.02 mm

Turning radius inside: 4.2 m

Statical line load: 77.8 kg/cm

Centrifugal force: 331 kN

Model series: H

Engine manuf.: Deutz

Engine type: TCD 6.1 L6

Engine power: 160 kW

Displacement: 6.057 l

Revolutions at max torque: 2300 rpm

No. of cylinders: 6

Emission level: Stage V

More technical details, like: drive, turning radius outside, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: No
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

Hamm H 25i FAQ

When was the Hamm H 25i manufactured?

The Hamm H 25i was first produced in 2014.

How much does the Hamm H 25i weigh?

The Hamm H 25i weighs 24.92 tons.

What are the transport dimensions of the Hamm H 25i single-drum roller?

The Hamm H 25i has a transport length of 6.6 meters, a transport width of 2.51 meters, and a transport height of 2.97 meters.

What is the travel speed of the Hamm H 25i single-drum roller?

The Hamm H 25i has a travel speed of 12 km/h.

What is the inside turning radius of the Hamm H 25i single-drum roller?

The Hamm H 25i has an inside turning radius of 4.2 meters.

What are the compaction capabilities of the Hamm H 25i single-drum roller?

The Hamm H 25i features a single vibration system with a frequency of 30 Hz, an amplitude of 2.02 mm, generates a centrifugal force of 331 kN, and has a statical line load of 77.8 kg/cm.

What are the roller specifications of the Hamm H 25i single-drum roller?

The Hamm H 25i has a roller width of 2.14 meters and a roller diameter of 1.6 meters.

How much is a Hamm H 25i Single-drum Roller (2014u20132025) worth?

The residual value of the Hamm H 25i depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
