CA15AD Rhino Dynapac CA15AD Rhino Specifications & Technical Data (2023—2026)
Visit Dynapac live at
.jpg){kind=logo}
Technical specs - CA15AD Rhino Dynapac
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 6.6 t
- Transport length
- 4.51 m
- Transport width
- 1.87 m
- Transport height
- 2.78 m
- Vibration
- e
- Drive
- A
- Travel speed
- 10 km/h
- Frequency
- 41 Hz
- Roller width
- 1.68 m
- Rollers Ø
- 1.22 m
- Turning radius outside
- 4.58 m
- Turning radius inside
- 2.9 m
- Statical line load
- 20 kg/cm
- Centrifugal force
- 96 kN
- Model series
- CA
- Engine manuf.
- Kubota
- Engine type
- V3307-DI
- Emission level
- Stage IIIA/Tier 3
More technical details, like: amplitude, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
