BW 226 DI-5 Bomag BW 226 DI-5 Specifications & Technical Data (2015—2026)
.jpg)
.jpg)
.jpg)
.jpg)
Visit Bomag live at
Technical specs - BW 226 DI-5 Bomag
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 26 t
- Transport length
- 6.742 m
- Transport width
- 2.5 m
- Transport height
- 3.078 m
- Vibration
- e
- Drive
- A
- Travel speed
- 10 km/h
- Frequency
- 26 Hz
- Roller width
- 2.13 m
- Rollers Ø
- 1.6 m
- Amplitude
- 2.42 mm
- Turning radius outside
- 4.26 m
- Model series
- BW
- Engine manuf.
- Deutz
- Engine type
- TCD6.1 L6
- Engine power
- 150 kW
- Displacement
- 6.1 l
- Revolutions at max torque
- 2200 rpm
More technical details, like: turning radius inside, statical line load, centrifugal force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
