Bomag BW 177 D-5
- Weight:
- 6.6 t
- Transport length:
- 4.54 m
- Transport width:
- 1.82 m
- Transport height:
- 2.8 m
Bomag BW 177 D-5 Specifications & Technical Data (2013-2025)
-
Model rating
- 6,00 / 10
.jpg)
.jpg)
.jpg)
.jpg)
Technical specs - BW 177 D-5 Bomag
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 6.6 t
- Transport length
- 4.54 m
- Transport width
- 1.82 m
- Transport height
- 2.8 m
- Vibration
- e
- Drive
- A
- Travel speed
- 10.5 km/h
- Frequency
- 31 Hz
- Roller width
- 1.69 m
- Rollers Ø
- 1.23 m
- Amplitude
- 1.9 mm
- Turning radius outside
- 2.98 m
- Statical line load
- 23.7 kg/cm
- Model series
- BW
- Engine manuf.
- Deutz
- Engine type
- TD2.9 L04
- Engine power
- 55.4 kW
- Revolutions at max torque
- 2400 rpm
More technical details, like: turning radius inside, centrifugal force, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
Yes
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
