BW 145 DH-5 Bomag BW 145 DH-5 Specifications & Technical Data (2013—2026)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Visit Bomag live at
Technical specs - BW 145 DH-5 Bomag
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 4.8 t
- Transport length
- 4.37 m
- Transport width
- 1.56 m
- Transport height
- 2.72 m
- Vibration
- e
- Drive
- A
- Travel speed
- 10 km/h
- Frequency
- 38 Hz
- Roller width
- 1.43 m
- Rollers Ø
- 1.06 m
- Amplitude
- 1.7 mm
- Turning radius outside
- 2.89 m
- Statical line load
- 17.7 kg/cm
- Model series
- BW
- Engine manuf.
- Kubota
- Engine type
- V3307CR-T
- Engine power
- 55.4 kW
- Displacement
- 3.3 l
- Revolutions at max torque
- 2400 rpm
- No. of cylinders
- 4
More technical details, like: turning radius inside, centrifugal force, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
