Ammann ASC 50 HDPD Specifications & Technical Data (2010-2022)

Technical specs - ASC 50 HDPD Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.8 t

Transport length: 4.03 m

Transport width: 1.542 m

Transport height: 2.48 m

Vibration: e

Drive: A

Frequency: 34 Hz

Roller width: 1.4 m

Rollers Ø: 1.15 m

Amplitude: 1.8 mm

Statical line load: 18.6 kg/cm

Model series: ASC

Engine manuf.: Kubota

Engine type: V3600

Engine power: 52.6 kW

Revolutions at max torque: 2650 rpm

More technical details, like: travel speed, turning radius outside, turning radius inside, centrifugal force, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: Yes
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

Ammann ASC 50 HDPD FAQ

When was the Ammann ASC 50 HDPD manufactured?

The Ammann ASC 50 HDPD was manufactured from 2010 to 2022.

How much does the Ammann ASC 50 HDPD weigh?

The Ammann ASC 50 HDPD weighs 4.8 tons.

What are the transport dimensions of the Ammann ASC 50 HDPD single-drum roller?

The Ammann ASC 50 HDPD has a transport length of 4.03 meters, a transport width of 1.54 meters, and a transport height of 2.48 meters.

What type of drive system does the Ammann ASC 50 HDPD have in its undercarriage?

The Ammann ASC 50 HDPD features an all-wheel drive system in its undercarriage.

What are the compaction capabilities of the Ammann ASC 50 HDPD single-drum roller?

The Ammann ASC 50 HDPD features a single vibration system with a frequency of 34 Hz, an amplitude of 1.8 mm, and a statical line load of 18.6 kg/cm.

What are the roller specifications of the Ammann ASC 50 HDPD single-drum roller?

The Ammann ASC 50 HDPD has a roller width of 1.4 meters and a roller diameter of 1.15 meters.
