ASC 200 HDPD Ammann ASC 200 HDPD Specifications & Technical Data (2007—2022)

Weight: 23t – Transport length: 6.3m – Transport width: 2.5m – Transport height: 3.3m – Vibration: e – Drive: A

Rollers Single-drum Rollers Ammann ASC 200 HDPD

ASC 200 HDPD

Years of manufacture: 2007—2022

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - ASC 200 HDPD Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 23 t

Transport length: 6.3 m

Transport width: 2.5 m

Transport height: 3.3 m

Vibration: e

Drive: A

Travel speed: 8 km/h

Frequency: 36 Hz

Roller width: 2.24 m

Rollers Ø: 1.7 m

Amplitude: 1.85 mm

Statical line load: 64 kg/cm

Model series: ASC

Engine manuf.: Cummins

Engine type: QSB6.7-C220

Engine power: 153 kW

Displacement: 6.7 l

Revolutions at max torque: 2200 rpm

More technical details, like: turning radius outside, turning radius inside, centrifugal force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Sheep foot: Yes
Oscillation: No
Compression control: Yes
Aircondition: No

Download datasheets (PDF)

Ammann ASC 200 HDPD FAQ

When was the Ammann ASC 200 HDPD manufactured?

The Ammann ASC 200 HDPD was manufactured from 2007 to 2022.

How much does the Ammann ASC 200 HDPD weigh?

The Ammann ASC 200 HDPD weighs 23 tons.

What are the transport dimensions of the Ammann ASC 200 HDPD single-drum roller?

The Ammann ASC 200 HDPD has a transport length of 6.3 meters, a transport width of 2.5 meters, and a transport height of 3.3 meters.

What is the travel speed of the Ammann ASC 200 HDPD?

The Ammann ASC 200 HDPD has a travel speed of 8 km/h.

What type of drive system does the Ammann ASC 200 HDPD have in its undercarriage?

The Ammann ASC 200 HDPD has an all-wheel drive system in its undercarriage.

What are the compaction capabilities of the Ammann ASC 200 HDPD single-drum roller?

The Ammann ASC 200 HDPD features a single vibration system with a frequency of 36 Hz, an amplitude of 1.85 mm, and a statical line load of 64 kg/cm.

What are the roller specifications of the Ammann ASC 200 HDPD single-drum roller?

The Ammann ASC 200 HDPD has a roller width of 2.24 meters and a roller diameter of 1.7 meters.
