Technical specs - ARS 50 Ammann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 4.165 t
- Transport length
- 3.925 m
- Transport width
- 1.548 m
- Transport height
- 2.545 m
- Vibration
- e
- Drive
- A
- Travel speed
- 12 km/h
- Frequency
- 29 Hz
- Roller width
- 1.4 m
- Rollers Ø
- 1 m
- Amplitude
- 1.6 mm
- Turning radius inside
- 3.27 m
- Statical line load
- 16.5 kg/cm
- Centrifugal force
- 37 kN
- Model series
- ARS
- Engine manuf.
- Kubota
- Engine type
- V2403-CR-T
- Engine power
- 43.2 kW
- Emission level
- EU V
More technical details, like: turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Sheep foot
-
Yes
- Oscillation
-
No
- Compression control
-
Yes
- Aircondition
-
No
