    Sinoway SWP1016H Specifications & Technical Data (2018-2022)

    Rate this machine now!

    Weight: 10t – Transport length: 4.98m – Transport width: 2.286m – Transport height: 3.22m – max. total weight: 16t – Travel speed : 14km/h

    Technical specs - SWP1016H Sinoway


    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight 10 t
    • Transport length 4.98 m
    • Transport width 2.286 m
    • Transport height 3.22 m
    • max. total weight 16 t
    • Travel speed 14 km/h
    • Roller width 2.286 m
    • Ballast weight 6 t
    • Wheels 4+5
    • Turning radius outside 7.5 m
    • Engine manuf. Cummins
    • Engine type 4BT3.9
    • Engine power 75 kW
    • Displacement 3.92 l
    • Revolutions at max torque 2200 rpm

    More technical details, like: drive, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

    Basic model with ROPS cabin

    Special equipment

    • Diesel particulate filter
    • Infrared heater
    • Edging press
    • Trailer coupling
