RPR109 RHINO RPR109 Specifications & Technical Data (2017—2026)
Technical specs - RPR109 RHINO
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 10 t
- Transport length
- 4.847 m
- Transport width
- 2.29 m
- Transport height
- 3.103 m
- max. total weight
- 16 t
- Travel speed
- 14 km/h
- Roller width
- 2.29 m
- Wheels
- 4 Front. 5 Rear
- Turning radius outside
- 7.5 m
- Model series
- RPR
- Engine manuf.
- Cummins
- Engine type
- 4BT3.9
- Engine power
- 73.5 kW
- Displacement
- 3.9 l
- Emission level
- Tier 2
More technical details, like: drive, ballast weight, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Infrared heater
-
No
- Edging press
-
No
- Trailer coupling
-
No
