PS 180 Caterpillar PS 180 Specifications & Technical Data (1992—2026)

Weight: 5.03t – Transport length: 4.14m – Transport width: 1.85m – Transport height: 2.64m – Travel speed: 38.6km/h – Turning radius outside: 5.91m

Rollers Rubber-wheeled Rollers Caterpillar PS 180

Technical specs - PS 180 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.03 t
Transport length
4.14 m
Transport width
1.85 m
Transport height
2.64 m
Travel speed
38.6 km/h
Turning radius outside
5.91 m
Model series
PS
Engine manuf.
Perkins
Engine type
4-236
Engine power
57 kW
Displacement
3.9 l
No. of cylinders
4

More technical details, like: drive, max. total weight, roller width, ballast weight, wheels, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Infrared heater
No
Edging press
No
Trailer coupling
No

Download specalog and datasheets (PDF)

Caterpillar PS 180 FAQ

When was the Caterpillar PS 180 manufactured?

The Caterpillar PS 180 was first produced in 1992.

How much does the Caterpillar PS 180 weigh?

The Caterpillar PS 180 weighs 5.03 tons.

What are the transport dimensions of the Caterpillar PS 180 rubber-wheeled roller?

The Caterpillar PS 180 has a transport length of 4.14 meters, a transport width of 1.85 meters, and a transport height of 2.64 meters.

What is the travel speed of the Caterpillar PS 180 rubber-wheeled roller?

The Caterpillar PS 180 has a travel speed of 38.6 km/h.

What is the turning radius of the Caterpillar PS 180 rubber-wheeled roller?

The Caterpillar PS 180 has an outside turning radius of 5.91 meters.
