CW16 Caterpillar CW16 Specifications & Technical Data (2019—2026)

Weight: 5.3t – Transport length: 4.29m – Transport width: 2.32m – Transport height: 3m – Travel speed: 19km/h – Wheels: 11

Rollers Rubber-wheeled Rollers Caterpillar CW16
Rollers Rubber-wheeled Rollers Caterpillar CW16
Rollers Rubber-wheeled Rollers Caterpillar CW16
Rollers Rubber-wheeled Rollers Caterpillar CW16
Rollers Rubber-wheeled Rollers Caterpillar CW16
Rollers Rubber-wheeled Rollers Caterpillar CW16

Technical specs - CW16 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.3 t
Transport length
4.29 m
Transport width
2.32 m
Transport height
3 m
Travel speed
19 km/h
Wheels
11
Turning radius outside
6.455 m
Model series
CW
Engine manuf.
Caterpillar
Engine type
C3.4B / C4.4
Engine power
75 kW
No. of cylinders
4
Emission level
Tier 4 f/ IV

More technical details, like: drive, max. total weight, roller width, ballast weight, dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter
No
Infrared heater
No
Edging press
No
Trailer coupling
No

Download specalog and datasheets (PDF)

Caterpillar CW16 FAQ

When was the Caterpillar CW16 manufactured?

The Caterpillar CW16 was first produced in 2019.

How much does the Caterpillar CW16 weigh?

The Caterpillar CW16 weighs 5.3 tons.

What are the transport dimensions of the Caterpillar CW16 rubber-wheeled roller?

The Caterpillar CW16 has a transport length of 4.29 meters, a transport width of 2.32 meters, and a transport height of 3 meters.

What is the travel speed of the Caterpillar CW16 rubber-wheeled roller?

The Caterpillar CW16 has a travel speed of 19 km/h.

How many wheels does the undercarriage of the Caterpillar CW16 have?

The undercarriage of the Caterpillar CW16 has 11 wheels.

What is the outside turning radius of the Caterpillar CW16 rubber-wheeled roller?

The Caterpillar CW16 has an outside turning radius of 6.455 meters.

How much is a Caterpillar CW16 Rubber-wheeled Roller (2019u20132025) worth?

The residual value of the Caterpillar CW16 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
