ART 35 Ammann ART 35 Specifications & Technical Data (2017—2021)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
Technical specs - ART 35 Ammann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 3.2 t
- Transport length
- 3.26 m
- Transport width
- 1.54 m
- Transport height
- 1.755 m
- max. total weight
- 3.2 t
- Travel speed
- 14.99 km/h
- Roller width
- 1.54 m
- Wheels
- 8
- Turning radius outside
- 2.02 m
- Model series
- ART
- Engine manuf.
- Deutz
- Engine type
- D2011 L03i
- Engine power
- 33.2 kW
- Revolutions at max torque
- 1700 rpm
- No. of cylinders
- 4
- Emission level
- Tier 4i
More technical details, like: drive, ballast weight, dimension lxwxh, displacement, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Infrared heater
-
No
- Edging press
-
No
- Trailer coupling
-
No
Download datasheets (PDF)
Ammann ART 35 FAQ
How much does the Ammann ART 35 weigh?
What are the transport dimensions of the Ammann ART 35 rubber-wheeled roller?
What is the travel speed of the Ammann ART 35 rubber-wheeled roller?
How many wheels does the Ammann ART 35 have on its undercarriage?
What is the outside turning radius of the Ammann ART 35 rubber-wheeled roller?
What is the roller width of the Ammann ART 35 rubber-wheeled roller?
How much is a Ammann ART 35 Rubber-wheeled Roller (2017u20132021) worth?
