AP 240 T3 Ammann AP 240 T3 Specifications & Technical Data (2013—2021)
.jpg)
.jpg)
.jpg)
.jpg)
Technical specs - AP 240 T3 Ammann
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 9.59 t
- Transport length
- 5.02 m
- Transport width
- 2.1 m
- Transport height
- 3.11 m
- Drive
- A
- max. total weight
- 24 t
- Travel speed
- 19 km/h
- Roller width
- 4.1 m
- Wheels
- 8
- Turning radius outside
- 6.18 m
- Model series
- AP
- Engine manuf.
- Cummins
- Engine type
- QSB3.3-C99
- Engine power
- 74 kW
- Displacement
- 3.3 l
- Revolutions at max torque
- 1400 rpm
- No. of cylinders
- 4
- Emission level
- Tier 3
More technical details, like: ballast weight, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Infrared heater
-
No
- Edging press
-
No
- Trailer coupling
-
Yes
Download datasheets (PDF)
