HD+ 110 VT Hamm HD+ 110 VT Specifications & Technical Data (2010—2022)
.jpg)
.jpg)
Visit Hamm live at
Technical specs - HD+ 110 VT Hamm
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 9.82 t
- Transport length
- 4.6 m
- Transport width
- 1.79 m
- Transport height
- 3.05 m
- Drive
- A
- Steering
- KL
- Travel speed
- 11 km/h
- Frequency
- 50 Hz
- Roller width
- 1.82 m
- Rollers Ø
- 1.2 m
- Statical line load
- 32.3 kg/cm
- Model series
- HD+
- Engine manuf.
- Deutz
- Engine type
- TCD2012 L04
- Engine power
- 100 kW
- Emission level
- III A
More technical details, like: vibration, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Infrared heater
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
Hamm HD+ 110 VT FAQ
How much does the Hamm HD+ 110 VT weigh?
What are the transport dimensions of the Hamm HD+ 110 VT?
What is the travel speed of the Hamm HD+ 110 VT?
What type of drive system does the Hamm HD+ 110 VT have in its undercarriage?
What type of steering does the Hamm HD+ 110 VT use for maneuverability?
What are the compaction capabilities of the Hamm HD+ 110 VT?
What are the roller specifications of the Hamm HD+ 110 VT?
How much is a Hamm HD+ 110 VT Combination Roller (2010u20132022) worth?
