Technical specs - CC 4200 C VI Dynapac
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 10 t
- Transport length
- 5.06 m
- Transport width
- 1.91 m
- Transport height
- 2.99 m
- Vibration
- d
- Drive
- A
- Travel speed
- 12 km/h
- Frequency
- 64 Hz
- Roller width
- 1.68 m
- Rollers Ø
- 1.3 m
- Turning radius outside
- 5.46 m
- Statical line load
- 29.8 kg/cm
- Model series
- CC
- Engine manuf.
- Cummins
- Engine type
- QSF3.8
- Engine power
- 97 kW
- Displacement
- 3.3 l
- Emission level
- T4f
More technical details, like: steering, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin
Special equipment
- Diesel particulate filter
-
No
- Infrared heater
-
No
- Oscillation
-
No
- Compression control
-
No
- Aircondition
-
No
Download datasheets (PDF)
Dynapac CC 4200 C VI FAQ
How much does the Dynapac CC 4200 C VI weigh?
What are the transport dimensions of the Dynapac CC 4200 C VI?
What is the travel speed of the Dynapac CC 4200 C VI?
What type of undercarriage drive does the Dynapac CC 4200 C VI have?
What is the outside turning radius of the Dynapac CC 4200 C VI?
What are the compaction capabilities of the Dynapac CC 4200 C VI?
What are the roller specifications of the Dynapac CC 4200 C VI?
How much is a Dynapac CC 4200 C VI Combination Roller (2017u20132025) worth?
