ARX 26.1-2C Ammann ARX 26.1-2C Specifications & Technical Data (2024—2026)

Weight: 4.32t – Transport length: 3m – Transport width: 1.385m – Transport height: 2.15m – Vibration: e – Drive: A

ARX 26.1-2C

Years of manufacture: 2024—2026

Valuate & Sell
Spare parts
Transport
News

Technical specs - ARX 26.1-2C Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.32 t

Transport length: 3 m

Transport width: 1.385 m

Transport height: 2.15 m

Vibration: e

Drive: A

Steering: KL

Travel speed: 10 km/h

Frequency: 55 Hz

Roller width: 1.3 m

Rollers Ø: 0.85 m

Turning radius outside: 2.83 m

Statical line load: 17.4 kg/cm

Model series: ARX

Engine manuf.: Yanmar

Engine type: 3TNV88F-EPAMM

Engine power: 18.5 kW

No. of cylinders: 3

Emission level: EU V

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Infrared heater: No
Oscillation: No
Compression control: Yes
Aircondition: No

Ammann ARX 26.1-2C FAQ

When was the Ammann ARX 26.1-2C manufactured?

The Ammann ARX 26.1-2C was first produced in 2024.

How much does the Ammann ARX 26.1-2C weigh?

The Ammann ARX 26.1-2C weighs 4.32 tons.

What are the transport dimensions of the Ammann ARX 26.1-2C?

The Ammann ARX 26.1-2C has a transport length of 3 meters, a transport width of 1.385 meters, and a transport height of 2.15 meters.

What is the travel speed of the Ammann ARX 26.1-2C?

The Ammann ARX 26.1-2C has a travel speed of 10 km/h.

What type of undercarriage drive does the Ammann ARX 26.1-2C have?

The Ammann ARX 26.1-2C has an all-wheel drive undercarriage.

What are the maneuverability specifications of the Ammann ARX 26.1-2C roller?

The Ammann ARX 26.1-2C has an articulated-frame steering system and an outside turning radius of 2.83 meters.

What are the compaction capabilities of the Ammann ARX 26.1-2C?

The Ammann ARX 26.1-2C features a single vibration system operating at a frequency of 55 Hz and has a statical line load of 17.4 kg/cm.

What are the roller specifications of the Ammann ARX 26.1-2C?

The Ammann ARX 26.1-2C has rollers with a width of 1.3 meters and a diameter of 0.85 meters.

How much is a Ammann ARX 26.1-2C Combination Roller (2024u20132025) worth?

The residual value of the Ammann ARX 26.1-2C depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
