ARP 35 K Ammann ARP 35 K Specifications & Technical Data (2013—2021)

Weight: 3.2t – Transport length: 3.1m – Transport width: 1.198m – Transport height: 1.755m – Vibration: e – Drive: A

Rollers Combination Rollers Ammann ARP 35 K

ARP 35 K

Years of manufacture: 2013—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - ARP 35 K Ammann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.2 t

Transport length: 3.1 m

Transport width: 1.198 m

Transport height: 1.755 m

Vibration: e

Drive: A

Steering: SL

Travel speed: 10 km/h

Frequency: 60 Hz

Roller width: 1.1 m

Rollers Ø: 0.8 m

Turning radius outside: 2.44 m

Statical line load: 15.1 kg/cm

Model series: Heavy Tandem Rollers

Engine manuf.: Deutz

Engine type: D2011 L03i

Engine power: 36 kW

Emission level: Tier 3

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin

Special equipment

Diesel particulate filter: No
Infrared heater: No
Oscillation: No
Compression control: No
Aircondition: No

Download datasheets (PDF)

Ammann ARP 35 K FAQ

When was the Ammann ARP 35 K manufactured?

The Ammann ARP 35 K was manufactured from 2013 to 2021.

How much does the Ammann ARP 35 K weigh?

The Ammann ARP 35 K weighs 3.2 tons.

What are the transport dimensions of the Ammann ARP 35 K?

The Ammann ARP 35 K has a transport length of 3.1 meters, a transport width of 1.2 meters, and a transport height of 1.76 meters.

What is the travel speed of the Ammann ARP 35 K?

The Ammann ARP 35 K has a travel speed of 10 km/h.

What type of drive system does the Ammann ARP 35 K use for its undercarriage?

The Ammann ARP 35 K uses an all-wheel drive system for its undercarriage.

What are the turning radius and steering type specifications of the Ammann ARP 35 K?

The Ammann ARP 35 K has an outside turning radius of 2.44 meters and features Center Pivot Plate Steering.

What are the compaction capabilities of the Ammann ARP 35 K?

The Ammann ARP 35 K features a single vibration system operating at 60 Hz and has a statical line load of 15.1 kg/cm.

What are the roller specifications of the Ammann ARP 35 K?

The Ammann ARP 35 K has rollers that are 1.1 meters wide with a diameter of 0.8 meters.
