XUT320 XCMG XUT320 Specifications & Technical Data (2025—2026)

Weight: 22.5t – Dump capacity: 10m³ – Net load: 22t – Steering: KL – Transport length: 9.121m – Transport width: 2.402m

Rigid Dump Trucks XCMG XUT320

Visit XCMG live at

Technical specs - XUT320 XCMG

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
22.5 t
Dump capacity
10 m³
Net load
22 t
Steering
KL
Transport length
9.121 m
Transport width
2.402 m
Transport height
2.49 m
Travel speed
26 km/h
Turning radius outside
7.355 m
Loading height
2.26 m
Model series
XUT
Engine manuf.
Volvo
Engine type
TAD883VE
Engine power
235 kW
Displacement
7.7 l
Max. torque
1310 Nm
No. of cylinders
6
Emission level
V

More technical details, like: standard tyres, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter
No
Central lubrication
No
Heated dump body
No
Tailgate
No
Aircondition
No
