540 Volvo 540 Specifications & Technical Data (1985—1987)
Visit Volvo live at
.jpg){kind=logo}
Technical specs - 540 Volvo
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 25.8 t
- Standard tyres
- 18.00-33/32 E3
- Dump capacity
- 23.5 m³
- Net load
- 36.3 t
- Transport length
- 8.08 m
- Transport width
- 3.73 m
- Transport height
- 3.72 m
- Travel speed
- 65 km/h
- Loading height
- 3.4 m
- Engine manuf.
- Scania
- Engine type
- DSI14
- Engine power
- 322 kW
- Displacement
- 14.2 l
- Revolutions at max torque
- 2100 rpm
- Max. torque
- 1695 Nm
- No. of cylinders
- 8
- Cylinder bore x stroke
- 127x140 mm
More technical details, like: steering, turning radius outside, model series, dimension lxwxh, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Central lubrication
-
No
- Heated dump body
-
No
- Tailgate
-
No
- Aircondition
-
No
