DP 905 WD Perlini DP 905 WD Specifications & Technical Data (2004—2016)

Weight: 65.5t – Standard tyres: 27.00x49 – Dump capacity: 42.4m³ – Net load: 95t – Steering: VL – Transport length: 11m

DP 905 WD

Years of manufacture: 2004—2016

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - DP 905 WD Perlini

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 65.5 t

Standard tyres: 27.00x49

Dump capacity: 42.4 m³

Net load: 95 t

Steering: VL

Transport length: 11 m

Transport width: 5.4 m

Transport height: 4.9 m

Travel speed: 63 km/h

Turning radius outside: 12.5 m

Loading height: 4.2 m

Engine manuf.: Detroit

Engine type: MTU 16 V 2000 TA

Engine power: 783 kW

Displacement: 31.86 l

Revolutions at max torque: 2100 rpm

More technical details, like: model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, passenger seat, air conditioner, telematics available, engine manufacturer, engine model, aspiration, cooling, engine output - gross, transmission type, drive configuration, final drive, speeds - forward, speeds - reverse, tyre size, retarder - type, length - overall, height - max, height - over canopy / rock guard rail, ground clearance, width - over tyres, width - transport, width - operating, wheelbase, length - body, loading height, full dump height, width - over body, hoist - angle, fuel tank, engine oil, cooling system, transmission - system, body type, struck capacity, heaped capacity, gears - forward / reverse, speed - forward maximum, net weight, payload, gross weight are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Central lubrication: Yes
Heated dump body: Yes
Tailgate: No
Aircondition: Yes

Download datasheets (PDF)

Perlini DP 905 WD FAQ

When was the Perlini DP 905 WD manufactured?

The Perlini DP 905 WD was manufactured from 2004 to 2016.

How much does the Perlini DP 905 WD weigh?

The Perlini DP 905 WD weighs 65.5 tons.

What are the transport dimensions of the Perlini DP 905 WD rigid dump truck?

The Perlini DP 905 WD has a transport length of 11 meters, a transport width of 5.4 meters, and a transport height of 4.9 meters.

What is the travel speed of the Perlini DP 905 WD rigid dump truck?

The Perlini DP 905 WD has a travel speed of 63 km/h.

What are the undercarriage specifications of the Perlini DP 905 WD rigid dump truck?

The Perlini DP 905 WD is equipped with standard tyres sized 27.00x49.

What are the maneuverability specifications of the Perlini DP 905 WD rigid dump truck?

The Perlini DP 905 WD has a front steering system and an outside turning radius of 12.5 meters.

What is the material handling capacity of the Perlini DP 905 WD rigid dump truck?

The Perlini DP 905 WD has a net load capacity of 95 tons and a dump capacity of 42.4 cubic meters.

How much is a Perlini DP 905 WD Rigid dump truck (2004u20132016) worth?

The residual value of the Perlini DP 905 WD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
