HD320-3 Komatsu HD320-3 Specifications & Technical Data (1984—1991)
Visit Komatsu live at
Technical specs - HD320-3 Komatsu
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 25.75 t
- Standard tyres
- 18.00-25-32 PR
- Dump capacity
- 24 m³
- Net load
- 32 t
- Transport length
- 7.65 m
- Transport width
- 3.67 m
- Transport height
- 3.85 m
- Turning radius outside
- 7.2 m
- Loading height
- 3.05 m
- Model series
- HD
- Engine manuf.
- Komatsu
- Engine type
- NTA855-C
- Engine power
- 313 kW
- Displacement
- 14.01 l
- Revolutions at max torque
- 2300 rpm
More technical details, like: steering, travel speed, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Central lubrication
-
No
- Heated dump body
-
No
- Tailgate
-
No
- Aircondition
-
No
