793D Caterpillar 793D Specifications & Technical Data (2017—2026)

Weight: 165.75t – Standard tyres: 40.00-R57 t – Dump capacity: 129m³ – Net load: 218t – Transport length: 12.86m – Transport width: 7.6m

793D

Years of manufacture: 2017—2026

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - 793D Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 165.75 t

Standard tyres: 40.00-R57 t

Dump capacity: 129 m³

Net load: 218 t

Transport length: 12.86 m

Transport width: 7.6 m

Transport height: 6.49 m

Travel speed: 54.3 km/h

Turning radius outside: 28.42 m

Loading height: 5.871 m

Engine manuf.: Caterpillar

Engine type: 3516B HD EUI

Engine power: 1743 kW

Displacement: 78 l

Cylinder bore x stroke: 170x215 mm

Emission level: Tier 1

More technical details, like: steering, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Central lubrication: No
Heated dump body: No
Tailgate: No
Aircondition: Yes

Download specalog and datasheets (PDF)

Caterpillar 793D FAQ

When was the Caterpillar 793D manufactured?

The Caterpillar 793D was first produced in 2017.

How much does the Caterpillar 793D weigh?

The Caterpillar 793D weighs 165.75 tons.

What are the transport dimensions of the Caterpillar 793D rigid dump truck?

The Caterpillar 793D has a transport length of 12.86 meters, a transport width of 7.6 meters, and a transport height of 6.49 meters.

What is the travel speed of the Caterpillar 793D rigid dump truck?

The Caterpillar 793D has a travel speed of 54.3 km/h.

What is the standard tyre size of the Caterpillar 793D?

The Caterpillar 793D has standard tyres of size 40.00-R57 t.

What is the turning radius of the Caterpillar 793D rigid dump truck?

The Caterpillar 793D has an outside turning radius of 28.42 meters.

What is the material handling capacity of the Caterpillar 793D rigid dump truck?

The Caterpillar 793D has a net load capacity of 218 tons, a dump capacity of 129 cubic meters, and a loading height of 5.87 meters.
