865R E Hybrid Sennebogen 865R E Hybrid Specifications & Technical Data (2024—2026)
Visit Sennebogen live at
.jpg){kind=logo}
Technical specs - 865R E Hybrid Sennebogen
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 110 t
- Boom
- UA
- Transport length
- 18.5 m
- Transport height
- 3.7 m
- Max. Reach horizontal
- 25 m
- Dredging depth
- 7.8 m
- Travel speed
- 3 km/h
- Track width
- 1500 mm
- Model series
- E
- Engine manuf.
- Cummins
- Engine type
- X12
- Engine power
- 261 kW
- Displacement
- 12 l
- Revolutions at max torque
- 1800 rpm
- No. of cylinders
- 6
- Emission level
- V
More technical details, like: standard tyres, outrigger stabilisers, transport width, tear-out force, dipper length, turning radius inside, turning radius outside, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.
