Technical specs - 850M E Sennebogen
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 62 t
- Standard tyres
- 14.00-24
- Boom
- UA
- Outrigger stabilisers
- 4 2/4-fold
- Transport length
- 16.4 m
- Transport height
- 3.85 m
- Transport width
- 3.6 m
- Max. Reach horizontal
- 21 m
- Travel speed
- 14 km/h
- Model series
- E
- Engine manuf.
- Cummins
- Engine type
- X 12
- Engine power
- 298 kW
- Revolutions at max torque
- 1800 rpm
- Emission level
- V
More technical details, like: dredging depth, tear-out force, dipper length, turning radius inside, turning radius outside, track width, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
