Sennebogen 840R E Specifications & Technical Data (2018-2021)

Technical specs - 840R E Sennebogen

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 59 t

Boom: UA

Transport length: 16.2 m

Transport height: 3.2 m

Transport width: 3 m

Max. Reach horizontal: 18 m

Track width: 700 mm

Model series: R

Engine manuf.: Cummins

Engine type: QSL9-C300

Engine power: 224 kW

Emission level: tier 4i

More technical details, like: standard tyres, outrigger stabilisers, dredging depth, tear-out force, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque...

More technical details, like: standard tyres, outrigger stabilisers, dredging depth, tear-out force, dipper length, turning radius inside, turning radius outside, travel speed, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Download datasheets (PDF)

Sennebogen 840R E FAQ

When was the Sennebogen 840R E manufactured?

The Sennebogen 840R E was manufactured from 2018 to 2021.

How much does the Sennebogen 840R E weigh?

The Sennebogen 840R E weighs 59 tons.

What are the transport dimensions of the Sennebogen 840R E material handler?

The Sennebogen 840R E has a transport length of 16.2 meters, a transport width of 3 meters, and a transport height of 3.2 meters.

What is the track width of the Sennebogen 840R E's undercarriage?

The Sennebogen 840R E has a track width of 700 mm.

What is the maximum horizontal reach and boom type of the Sennebogen 840R E?

The Sennebogen 840R E has a maximum horizontal reach of 18 meters and is equipped with a material handling boom.

How much is a Sennebogen 840R E Material handler (2018u20132021) worth?

The residual value of the Sennebogen 840R E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
