Technical specs - 835M E Sennebogen
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 45.5 t
- Standard tyres
- 8x12.00-20
- Boom
- UA
- Outrigger stabilisers
- 4 2/4-fold
- Transport length
- 13.5 m
- Transport height
- 3.45 m
- Transport width
- 4.465 m
- Max. Reach horizontal
- 20 m
- Travel speed
- 20 km/h
- Model series
- E
- Engine manuf.
- Cummins
- Engine type
- L9
- Engine power
- 231 kW
- Displacement
- 9 l
- Revolutions at max torque
- 2100 rpm
- No. of cylinders
- 6
- Emission level
- V
More technical details, like: dredging depth, tear-out force, dipper length, turning radius inside, turning radius outside, track width, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.
Download datasheets (PDF)
Sennebogen 835M E FAQ
How much does the Sennebogen 835M E weigh?
What are the transport dimensions of the Sennebogen 835M E material handler?
What is the travel speed of the Sennebogen 835M E material handler?
What are the undercarriage specifications of the Sennebogen 835M E material handler?
What are the reach and boom specifications of the Sennebogen 835M E material handler?
