Sennebogen 8100 EQ Specifications & Technical Data (2023-2026)

Technical specs - 8100 EQ Sennebogen

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 129 t

Boom: UA

Transport width: 6.4 m

Max. Reach horizontal: 24 m

Dredging depth: 8 m

Travel speed: 1.3 km/h

Track width: 900 mm

Model series: EQ

Engine manuf.: Cummins

Engine type: QSB 4,5

Engine power: 129 kW

Emission level: Tier IVf

More technical details, like: standard tyres, outrigger stabilisers, transport length, transport height, tear-out force, dipper length, turning radius inside, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque...

More technical details, like: standard tyres, outrigger stabilisers, transport length, transport height, tear-out force, dipper length, turning radius inside, turning radius outside, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Download datasheets (PDF)

8100 EQ Sennebogen Specification for Global (DE,EN)

Sennebogen 8100 EQ FAQ

When was the Sennebogen 8100 EQ manufactured?

The Sennebogen 8100 EQ was first produced in 2023.

How much does the Sennebogen 8100 EQ weigh?

The Sennebogen 8100 EQ weighs 129 tons.

What is the transport width of the Sennebogen 8100 EQ material handler?

The Sennebogen 8100 EQ has a transport width of 6.4 meters.

What is the travel speed of the Sennebogen 8100 EQ material handler?

The Sennebogen 8100 EQ has a travel speed of 1.3 km/h.

What is the track width of the Sennebogen 8100 EQ's undercarriage?

The Sennebogen 8100 EQ has a track width of 900 mm.

What are the excavation performance specifications of the Sennebogen 8100 EQ?

The Sennebogen 8100 EQ has a dredging depth of 8 meters, a maximum horizontal reach of 24 meters, and is equipped with a material handling boom.

How much is a Sennebogen 8100 EQ Material handler (2023u20132025) worth?

The residual value of the Sennebogen 8100 EQ depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
