M40 Minelli M40 Specifications & Technical Data (2023—2026)

Weight: 40t – Standard tyres: 12.00x20” – Outrigger stabilisers: 42/4-fold – Transport length: 12.65m – Transport height: 3.51m – Transport width: 2.95m

Material Handlers Minelli M40
Material Handlers Minelli M40
Material Handlers Minelli M40
Material Handlers Minelli M40
Material Handlers Minelli M40
Material Handlers Minelli M40
Material Handlers Minelli M40
Material Handlers Minelli M40
Material Handlers Minelli M40
Material Handlers Minelli M40
Material Handlers Minelli M40
Material Handlers Minelli M40
Material Handlers Minelli M40
Material Handlers Minelli M40

Technical specs - M40 Minelli

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
40 t
Standard tyres
12.00x20”
Outrigger stabilisers
4 2/4-fold
Transport length
12.65 m
Transport height
3.51 m
Transport width
2.95 m
Max. Reach horizontal
16 m
Travel speed
23 km/h
Model series
M
Engine manuf.
Perkins
Engine type
1206J-E70TTA
Engine power
205 kW
Displacement
7 l
Revolutions at max torque
1500 rpm
Max. torque
1257 Nm
No. of cylinders
6
Emission level
EU Stage V

More technical details, like: boom, dredging depth, tear-out force, dipper length, turning radius inside, turning radius outside, track width, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Download datasheets (PDF)

Minelli M40 FAQ

When was the Minelli M40 manufactured?

The Minelli M40 was first produced in 2023.

How much does the Minelli M40 weigh?

The Minelli M40 weighs 40 tons.

What are the transport dimensions of the Minelli M40 material handler?

The Minelli M40 has a transport length of 12.65 meters, a transport width of 2.95 meters, and a transport height of 3.51 meters.

What is the travel speed of the Minelli M40 material handler?

The Minelli M40 material handler has a travel speed of 23 km/h.

What are the undercarriage specifications of the Minelli M40 material handler?

The Minelli M40 is equipped with 12.00x20u201d standard tyres and has 4 outrigger stabilisers (2/4-fold).

What is the maximum horizontal reach of the Minelli M40 material handler during excavation?

The Minelli M40 has a maximum horizontal reach of 16 meters during excavation.
