M30 Minelli M30 Specifications & Technical Data (2023—2026)

Weight: 30t – Standard tyres: 10.00x20” – Outrigger stabilisers: 22/4-fold – Transport length: 9.82m – Transport height: 3.275m – Transport width: 2.55m

Material Handlers Minelli M30
Material Handlers Minelli M30
Material Handlers Minelli M30
Material Handlers Minelli M30
Material Handlers Minelli M30
Material Handlers Minelli M30
Material Handlers Minelli M30
Material Handlers Minelli M30
Material Handlers Minelli M30
Material Handlers Minelli M30
Material Handlers Minelli M30
Material Handlers Minelli M30

Technical specs - M30 Minelli

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
30 t
Standard tyres
10.00x20”
Outrigger stabilisers
2 2/4-fold
Transport length
9.82 m
Transport height
3.275 m
Transport width
2.55 m
Max. Reach horizontal
11.7 m
Travel speed
12 km/h
Model series
M
Engine manuf.
Perkins
Engine type
1206J-E70TA
Engine power
151 kW
Displacement
7.01 l
Revolutions at max torque
2200 rpm
Max. torque
870/1400 Nm
No. of cylinders
6
Cylinder bore x stroke
105x135 mm
Emission level
Euro V

More technical details, like: boom, dredging depth, tear-out force, dipper length, turning radius inside, turning radius outside, track width, dimension lxwxh are available in the full technical specs.
