MH3026 Caterpillar MH3026 Specifications & Technical Data (2025—2026)
Technical specs - MH3026 Caterpillar
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 29.2 t
- Standard tyres
- 10.00-20
- Boom
- MB
- Transport length
- 11.2 m
- Transport height
- 3.4 m
- Transport width
- 2.99 m
- Max. Reach horizontal
- 13 m
- Dredging depth
- 2.97 m
- Turning radius inside
- 6.9 m
- Travel speed
- 20 km/h
- Model series
- MH
- Engine manuf.
- Caterpillar
- Engine type
- C7.1
- Engine power
- 129 kW
- Displacement
- 7.01 l
- Max. torque
- 830/1400 Nm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 105x135 mm
- Emission level
- V
More technical details, like: outrigger stabilisers, tear-out force, dipper length, turning radius outside, track width, dimension lxwxh, revolutions at max torque are available in the full technical specs.
Download specalog and datasheets (PDF)
Caterpillar MH3026 FAQ
How much does the Caterpillar MH3026 weigh?
What are the transport dimensions of the Caterpillar MH3026 material handler?
What is the travel speed of the Caterpillar MH3026 material handler?
What are the undercarriage specifications of the Caterpillar MH3026?
What is the turning radius inside of the Caterpillar MH3026 material handler?
What are the excavation performance specifications of the Caterpillar MH3026 material handler?
How much is a Caterpillar MH3026 Material handler (2025u20132025) worth?
