GR180 XCMG GR180 Specifications & Technical Data (2026—2026)

Weight: 15.4t – Standard tyres: 17.5-25 – Transport length: 8.9m – Transport width: 2.625m – Transport height: 3.42m – Mouldboard width: 3.66m

Graders XCMG GR180
Graders XCMG GR180
Graders XCMG GR180
Graders XCMG GR180
Graders XCMG GR180
Graders XCMG GR180
Graders XCMG GR180
Graders XCMG GR180
Graders XCMG GR180
Graders XCMG GR180

Visit XCMG live at

Technical specs - GR180 XCMG

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
15.4 t
Standard tyres
17.5-25
Transport length
8.9 m
Transport width
2.625 m
Transport height
3.42 m
Mouldboard width
3.66 m
Travel speed
38 km/h
Model series
GR
Engine manuf.
Cummins
Engine type
6CTA8.3-C190-II
Engine power
132 kW
Revolutions at max torque
2200 rpm
Emission level
EU II

More technical details, like: steering mode, drive, front blade width, turning radius outside, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter
No
Bilateral levelling automatic
No
Front blade
No
Rear ripper
Yes
Aircondition
No
