G9290H SDLG G9290H Specifications & Technical Data (2026—2026)

Weight: 25.8t – Transport length: 10.608m – Transport width: 3.428m – Transport height: 3.39m – Mouldboard width: 4.267m – Travel speed: 44.9km/h

Technical specs - G9290H SDLG

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
25.8 t
Transport length
10.608 m
Transport width
3.428 m
Transport height
3.39 m
Mouldboard width
4.267 m
Travel speed
44.9 km/h
Turning radius outside
8 m
Model series
H
Engine manuf.
Weichai
Engine type
WP10G336E341
Engine power
247 kW
Revolutions at max torque
1500 rpm
Max. torque
1550 Nm
Emission level
GB 20891-2014(stage III)

More technical details, like: standard tyres, steering mode, drive, front blade width, dimension lxwxh, displacement, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter
No
Bilateral levelling automatic
No
Front blade
No
Rear ripper
No
Aircondition
No
