4260D Liugong 4260D Specifications & Technical Data (2023—2026)

Weight: 20.5t – Standard tyres: 20.5-25 – Transport length: 9.68m – Transport width: 2.86m – Transport height: 3.53m – Mouldboard width: 4.27m

Graders Liugong 4260D
Graders Liugong 4260D
Graders Liugong 4260D
Graders Liugong 4260D

Visit Liugong live at

Technical specs - 4260D Liugong

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
20.5 t
Standard tyres
20.5-25
Transport length
9.68 m
Transport width
2.86 m
Transport height
3.53 m
Mouldboard width
4.27 m
Travel speed
44 km/h
Turning radius outside
7.5 m
Model series
D
Engine manuf.
Cummins
Engine type
6CTAA8.3
Engine power
194 kW
Revolutions at max torque
1400 rpm
Max. torque
1100 Nm
No. of cylinders
6
Emission level
Tier 2/Stage II

More technical details, like: steering mode, drive, front blade width, dimension lxwxh, displacement, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and central blade

Special equipment

Diesel particulate filter
No
Bilateral levelling automatic
No
Front blade
No
Rear ripper
No
Aircondition
No
